Pluggable Terminal Block-Plugs

Pluggable Terminal Block-PlugsLKPGH-350
LKPGH-350

3.50mm,Spring plug

Basic information
Type
Pluggable Terminal Block-Plugs
ClassificationSpring plug
ModelLKPGH-350
Pitch3.50mm
Number of connections02P~16P
ColorGreen
Main technical parameters
Pitch[mm]3.50
Technical data ,in accordance with IEC/DIN and VDE
Insulating material group I
Surge voltage category/Contamination classIII/3  III/2  II/2
Rated voltage[V]160  200  400
Rated surge voltage[kV]2.5   2.5  2.5
Nominal current/Cross section[A]/[mm2]6/1.5
Maximum load curren/Cross section[A]/[mm2]6/1.5
Capacity connection
Rigid wire/flexible wire/Wire gauge[mm2]/[mm2]/AWG0.2-1.5/0.2-1.5/24-16
Flexible wire with cold press head  with/without plastic sleeve0.25-0.75/0.2-1.5
Multi wire connection(Two wires with the same cross-sectional area)
Rigid wire/flexible wire[mm2]-
Flexible wire with cold press head  with/without plastic sleeve[mm2]-
Flexible wire with cold press head  with plastic sleeve[mm2]-
Stripping length[mm]10
Internal cylindrical gauge(IEC 60 947-1)A1
Thread-
Torque[Nm]-
Insulating materialPBT
Inflammability class in acc.with UL 94V0
Approva ldata(UL/CUL/CSA)
Rated voltage/Nominal current/Wire gauge  UL/CUL:[V]/[A]/AWG-/-/-
                                             CSA:[V]/[A]/AWG-/-/-
Accessory products
Related products

If you want to have a comprehensive and in-depth understanding of our products, Jointlean can provide samples for users to experience
